Semi Automatic Tube Filling Machine

• Capable to fills from 5 grm. To 250 grm. All Contact Parts will be SS 316
• Filling System -Positive Suction & Displacement. Attached Pneumatic Blow Tail Cut-off with Control System
• No tube - No fill Device. And Bottom up Filling System. Filling Accuracy +/ - 0.1%
• Tube Sizes max. Length & Diameter: 10 to 60 mm dia./ Length: 40 to 210 mm
• 12 Nos.Tube holding Cup SS-304
• Indexing System Geneva Mechanism
• Syringe Pump Single Head Type Insert for Filling (5 Gms. to 30 Gms.) (30 Gms. to 100 Gms.) (100 Gms. to 250 Gms.)
• Jacketed Hopper Double Head Type of Capacity of 40 liters
• Temperature Controller With 3KW SS Tubular Heater
• Belt Less Stirrer Device with augur to keep the product in Continuous homogeneous condition
• Feeding the empty tubes manually, and filling, sealing, Coding and Tube Ejector automatically
• Lami / plastic Tube heating device Activate on Leicester Model Type 3000 Hot Air Tool 8D1 Swiss Make one set
• With Hot air Tool adopter Jacketed SS-304, one set and tube-heating adopter cooling ring centers the tube so That heating is uniform around the tube
• Blower: 0.5 HP (MINI VAC Make) one set
• Lami / plastic Tube Sealing Device Activate on Pneumatics
• In sealing & coding wherein the tube is pressed & sealed and then coded with metal stereos coding letter punch (female 0 to 9, one set)
• Machine body Construction Mild Steel 50mm Sq
• Box type and Machine bash plate 19mm heavy duty fabricated, with Epoxy Powder Coated And all Safety Cover 18 gauge SS 304
• Electronic Digital filled Tube Production Counter
• Overload Clutch for Centering and Micro Switch Cut-Off System
